BAScontrol series - BACnet/IP Sedona Unitary Controllers
Controller, I/O, Sedona, BACnet Server or BACnet Client/Server models
Controllers in the series support a common core of features and differ only by I/O count and network connections. Configuration is via a 10/100 Mbps Ethernet connection. All models have a real-time clock and are powered from a 24 VAC/VDC power source.
Product
Analytics, Analytics,Access Control, Access Control,Appliances, Appliances,Asia Pacific, Asia Pacific,Building Automation, Building Automation,Central America, Central America,Controllers, Controllers,Data Centers, Data Centers,Developer, Developer,Distributor / Reseller, Distributor / Reseller,Education, Education,EMEA, EMEA,Energy Mgmt., Energy Mgmt.,Enterprise Mgmt., Enterprise Mgmt.,Equipment Control, Equipment Control,Industrial, Industrial,Intelligent Lighting, Intelligent Lighting,N. America, N. America,OEM, OEM,Refrigeration, Refrigeration,Renewables, Renewables,S. America, S. America,Stand-alone Applications, Stand-alone Applications,Systems Integrator, Systems Integrator,
BASautomation
2/26/2016
Product
Analytics, Analytics,Access Control, Access Control,Appliances, Appliances,Asia Pacific, Asia Pacific,Building Automation, Building Automation,Central America, Central America,Controllers, Controllers,Data Centers, Data Centers,Developer, Developer,Distributor / Reseller, Distributor / Reseller,Education, Education,EMEA, EMEA,Energy Mgmt., Energy Mgmt.,Enterprise Mgmt., Enterprise Mgmt.,Equipment Control, Equipment Control,Industrial, Industrial,Intelligent Lighting, Intelligent Lighting,N. America, N. America,OEM, OEM,Refrigeration, Refrigeration,Renewables, Renewables,S. America, S. America,Stand-alone Applications, Stand-alone Applications,Systems Integrator, Systems Integrator,
BASautomation
2/26/2016
Description
Controllers in the series support a common core of features and differ only by I/O count and network connections. Configuration is via a 10/100 Mbps Ethernet connection. All models have a real-time clock and are powered from a 24 VAC/VDC power source.
By operating at the BACnet/IP level, the BAScontrol can share the same Ethernet network with supervisory controllers and operator workstations. A real-time clock with a supercap backup allows for creating local schedules.
A 10/100 Mbps Ethernet port supports protocols such as BACnet/IP, Sedona SOX, HTTP and FTP. Configuration of universal inputs and virtual points can be accomplished using web pages. Type II and type III 10 kΩ thermistor curves and a 20 kΩ thermistor curve are resident in the unit. Current inputs can be measured using external resistors. Contact closures require a voltage-free source. Binary inputs and outputs as well as analogue outputs require no configuration. The unit is powered from either a 24VAC/VDC source.
BACnet servers serve up their points to BACnet clients. Writable BACnet server device points can also be written to by BACnet clients. The BAScontrol20C/22C is capable of directly reading from and writing to BACnet/IP devices on the network by the use of NetV (Network Variable) Sedona components. NetV components allow the BAScontrol20C/22C to read and/or write Analog Input (AI), Binary Input (BI), Analog Value (AV), Binary Value (BV), Analog Output (AO), and Binary Output (BO) BACnet object types in its wire sheet. In addition, with a BACnet router in place (such as BASRT-B or BASRTLX-B), the BAScontrol20C/22C is capable of reading from and/or writing to BACnet MS/TP devices which are being routed to BACnet/IP. The points obtained over the BACnet network can be used in the BAScontrol20C/22C's Sedona wire sheet application logic, become scaled, calculated, and/or converted to different data types, written to other BACnet devices, served up to BACnet supervisory controllers and operator workstations by using Virtual Components, as well as be monitored, displayed, or exposed for configuration on BAScontrol20C/22C's web page by the use of Web Components.
Package Details
3.8;4.0;4.1;4.2;4.3;4.4;4.6;4.8;4.9JACE 8000;PC
Chrome;Firefox;Internet Explorer;Opera;Safari
Free Sedona Application Editor (SAE) from Contemporary Controls
Contact Information
Website: https://ccontrols.eu/bascontrol-bacnet-ip-sedona-unitary-controller/Email: info@ccontrols.co.uk
Phone: +44 (0)24 7641 3786
