BASgatewayLX


Modbus to BACnet Gateway
 (1)
No review (0)
To make Modbus devices appear as individual BACnet devices a BASgatewayLX is used. The BASgatewayLX supports up to 100 Modbus serial devices with each device appearing as an individual BACnet device. Modbus device profiles for common Modbus devices are available from Contemporary Controls and custom device profiles are created upon request, free of charge.

 Product

 Analytics, Analytics,Access Control, Access Control,Asia Pacific, Asia Pacific,Building Automation, Building Automation,Central America, Central America,Controllers, Controllers,Data Centers, Data Centers,Distributor / Reseller, Distributor / Reseller,Education, Education,EMEA, EMEA,Energy Mgmt., Energy Mgmt.,Enterprise Mgmt., Enterprise Mgmt.,Equipment Control, Equipment Control,Industrial, Industrial,Intelligent Lighting, Intelligent Lighting,N. America, N. America,OEM, OEM,Refrigeration, Refrigeration,Renewables, Renewables,S. America, S. America,Systems Integrator, Systems Integrator,

 BASautomation

 2/26/2016


BASgatewayLX
View Video

Description


To make Modbus devices appear as individual BACnet devices a BASgatewayLX is used. The BASgatewayLX supports up to 100 Modbus serial devices with each device appearing as an individual BACnet device. Modbus device profiles for common Modbus devices are available from Contemporary Controls and custom device profiles are created upon request, free of charge.

To make Modbus devices appear as individual BACnet devices a BASgatewayLX is used. This device has one 10/100 Mbps Modbus TCP and BACnet/IP Ethernet port and an opto-isolated Modbus EIA-485 serial port for Modbus RTU or Modbus ASCII devices. Up to 100 Modbus serial devices represented by up to 1000 polled points can share the single Modbus EIA-485 port on the BASgatewayLX. BACnet COV notification is supported on 200 points (100 Analog and 100 Binary points). The virtual routing feature in the BASgatewayLX allows each connected Modbus device to appear as an individual BACnet compliant device.
Modbus data points from Modbus Serial or Modbus TCP/IP devices can be mapped to BACnet objects.

The BASgatewayLX is housed in a metal case that mounts on 35-mm DIN-rail and it is powered from a 24 VAC/VDC (± 10%) source. Its half-wave rectified power supply allows sharing of power with other half-wave devices.
The optically-isolated serial port allows for connection to either 2-wire or 3-wire EIA-485 networks using a removable 5-pin terminal block. Up to 100 EIA-485 Modbus devices can share the serial bus at data rates between 2.4 and 115.2 kbps. Internal jumpers allow flexible bias and termination options. They can be removed for mid-span installations.
The Ethernet port offers a shielded RJ-45 connector. Through auto-negotiation and Auto-MDIX, it automatically matches connections to the attached equipment. Therefore, either CAT5 straight-through or crossover cable can be used to attach to the BACnet/IP or Modbus TCP network at either 10 or 100 Mbps speed.
A resident web server allows for commissioning, and troubleshooting via a standard web browser.


Package Details

 3.0;3.1;3.2;3.3;3.4;3.5;3.6;3.7;3.8;4.0;4.1;4.2;4.3;4.4;4.6;4.8;4.9
 JACE 2;JACE4;JACE 5;JACE-NXT;JACE 3E;JACE 6/6E;JACE 7;JACE 8000;PC
 Firefox;Internet Explorer;Opera;Safari
 Bacnet Protocol Revision 6
