Description
The BASpi-Edge series are hardened controllers with enhanced features and data processing at the Edge functionality, powered by Raspberry Pi. Housed in a compact DIN rail mounted enclosure with 24 VAC/VDC power input, flexible Input/Output — 12-points of physical I/O and a resilient pSLC 8 GB micro SD card gives them performance and convenience advantages, making them suitable for a wide array of applications.
BASpi-Edge controllers utilize the powerful 1.2 GHz 64-bit CPU in the Raspberry Pi 3 with 1 GB of RAM memory for lightning fast operation, its Ethernet and Wi-Fi adapters for versatile network connectivity, USB ports for extended functionality, as well as its HDMI port for human-machine interface for touchscreen or display options. Our field-proven, resilient I/O and power circuit board installed on top hardens the RPi3 and allows it to safely interface with standard building automation input/output control signals.
The BASpi-Edge is fully web page configurable with secure web page authentication. By operating at the BACnet/IP level with a B-ASC device profile, BASpi-Edge can share the same Ethernet or Wi-Fi network with BACnet supervisory controllers and operator workstations. Universal input channels are set for 0-10 V input by default and are configurable for type II and type III 10 kΩ thermistor curves, a 20 kΩ thermistor curve, pulse inputs with or without pull up at up to 40 Hz, or binary contact closure inputs (require a voltage-free source). An NTP server or manually-settable clock allows for creating local schedules with holidays/exceptions. Email alarms/notifications are also web page configurable and allow for points or direct wire sheet values to be included in the sent emails. A configurable weather station using weather server provides timely weather data parameters right to your wire sheet logic, BACnet/IP network, graphical dashboard, or pushed to the Azure IoT dashboard. Graphical dashboards can be customized and accessed over Ethernet, Wi-Fi, or directly out of the resident HDMI port. A built-in library of graphical widgets such as gauges, charts, sliders, or buttons is used to display and/or control BASpi-Edge point values. The built in cloud connector allows for quick and easy connection to Azure IoT Central SaaS (Software as a Service) cloud solution - data can be trended, visualized, analysed, alarmed, and accessed from anywhere.
Package Details
3.8;4.0;4.1;4.2;4.3;4.4;4.6;4.8;4.9JACE 8000;PC
Chrome;Firefox;Internet Explorer;Opera;Safari
Free Sedona Application Editor (SAE) from Contemporary Controls
